Compare models of 60Hz Diesel Rental Generators Print

Print

G25WMI-2A-T4i

Add model
Add model

Select a model

Select a model G145WJD-2A-T3 G185WJD-2A-T3 G240WJD-2B-T3 G290WCU-3B-T3 G40WMI-2A-T4i G450WCU-2B-T2 G570WCU-2B-T2 G70WJD-2A-T3 G90WJD-2A-T3 Add

Select a model

Select a model G145WJD-2A-T3 G185WJD-2A-T3 G240WJD-2B-T3 G290WCU-3B-T3 G40WMI-2A-T4i G450WCU-2B-T2 G570WCU-2B-T2 G70WJD-2A-T3 G90WJD-2A-T3 Add

PRIME POWER RATING

@ 480V-3Ø, 0.8PF, 60Hz
@ 480V-3Ø, 0.8PF, 60Hz
25 kVA (20 kW ), 30 Amps
@ 240V-3Ø, 0.8PF, 60Hz
@ 240V-3Ø, 0.8PF, 60Hz
25 kVA (20 kW ), 60 Amps
25 kVA (20 kW ), 60 Amps
@ 208V-3Ø, 0.8PF, 60Hz
@ 208V-3Ø, 0.8PF, 60Hz
25 kVA (20 kW ), 69 Amps
@ 240V-1Ø, 1.0PF, 60Hz 4 Wire / Zig-Zag
@ 240V-1Ø, 1.0PF, 60Hz 4 Wire / Zig-Zag
20 kVA (20 kW ), 28 Amps / 15.6 kVA (15.6 kW ), 65 Amps
20 kVA (20 kW ), 28 Amps / 15.6 kVA (15.6 kW ), 65 Amps
@ 120V-1Ø, 1.0PF, 60Hz 4 Wire / Zig-Zag
@ 120V-1Ø, 1.0PF, 60Hz 4 Wire / Zig-Zag
20 kVA (20 kW ), 56 Amps / 15.6 kVA (15.6 kW ), 65x2 Amps
Voltage Configuration
Voltage Configuration
3-Position Switch
3-Position Switch
Frequency Capability
Frequency Capability
60Hz Only

ENGINE

Engine Make / Model
Engine Make / Model
Mitsubishi S4Q2-Y362
Power Output @ 1800RPM - HP (kWm)
Power Output @ 1800RPM - HP (kWm)
31 (23)
31 (23)
Emissions Tier Level
Emissions Tier Level
Tier 4-interim
Fuel Tank Capacity - Gal (L)
Fuel Tank Capacity - Gal (L)
36 (136)
36 (136)
Runtime @ 100% Load - Hr
Runtime @ 100% Load - Hr
18,9

DIMENSIONS w/ running gear

Length - in (mm)
Length - in (mm)
131 (3327)
Width - in (mm)
Width - in (mm)
59.5 (1511)
59.5 (1511)
Height - in (mm)
Height - in (mm)
67 (1702)
Weight (Ready to Run) - lb (kg)
Weight (Ready to Run) - lb (kg)
2588 (1174)
2588 (1174)
Sound Level @ 23 ft (7m) and 100% Load - dB(A)
Sound Level @ 23 ft (7m) and 100% Load - dB(A)
66
